Trailed Spraying Machine
  • Trailed Spraying MachineTrailed Spraying Machine
  • Trailed Spraying MachineTrailed Spraying Machine
  • Trailed Spraying MachineTrailed Spraying Machine
  • Trailed Spraying MachineTrailed Spraying Machine
  • Trailed Spraying MachineTrailed Spraying Machine

Trailed Spraying Machine

Welcome to wholesale Trailed Spraying Machine from us, every request from customers is being replied within 24 hours. Harvester Machinery is the professional manufacturer, we would like to provide you Trailed Spraying Machine and we will offer you the best after-sale service and timely delivery. The Trailed Spraying Machine has become an indispensable tool in modern agriculture, providing many advantages for fruit growers. These multifunctional machines are designed to efficiently apply pesticides, herbicides, and fertilizers on large orchards. By using a towed spray, farmers can significantly improve crop protection strategies, increase productivity, and reduce overall costs.

Send Inquiry

Product Description

The following is an introduction to Trailed Spraying Machine, Harvester Machinery hope to help you better understand Trailed Spraying Machine. Welcome new and old customers to continue to cooperate with us to create a better future together! The Trailed Spraying Machine, as our company's latest innovative achievement, is designed specifically for orchard management and is suitable for large orchards. Its power source is the output power from the rear of the tractor, requiring a tractor with over 50 horsepower for traction. The capacity of the medicine box of the machine has a variety of specifications, from 800L to 2000L. The medicine box is made of high-density polyethylene materials in one time, with an average wall thickness of 15mm and anti-aging. The Trailed Spraying Machine atomizes the medicine through the pressure of the medicine pump, and relies on a fan to generate a strong airflow to blow the mist towards various parts of the fruit tree. The high-speed airflow of the fan helps the mist penetrate the dense branches and leaves of the fruit tree, promoting the flipping of the leaves and increasing the adhesion rate of the medicinal solution, without damaging the branches or fruits of the fruit tree. It can be used for multiple purposes, not only for spraying medicine, but also for watering seedlings, root irrigation of fruit trees, and liquid fertilization.



There are various types and specifications of Trailed Spraying Machine to choose from, including different medicine box volumes, spraying widths, and overall machine weights, to meet the needs of different orchards.

Model 3WFQ-800 3WFQ-1000 3WFQ-1200 3WFQ-1500 3WFQ-2000
Max Capacity(L) 800 1000 1200 1500 2000
Dimension(MM) 2300*13000*1400 2660*1300*1460 3100*1400*1500 3300*1400*1500 3720*1510*1630
Horizontal Range(MM) 20000 22000 22000 22000 22000
Working Pressure(Mpa) 0.5-1.0 0.5-1.0 0.8-1.0 0.8-1.0 0.8-1.0
Pump Diaphragm pump
Matched Power(HP) ≥50 ≥50 ≥50 ≥50 ≥50
Rated Flow(L/min) 80-100 80-100 80-100 80-100 100-140

The impact of different capacity specifications of Trailed Spraying Machine on work efficiency and speed is mainly reflected in the following aspects:
1. Single operation range: The larger the capacity of the medicine box, the wider the area that can be covered after a single dosing, thereby reducing the number of dosing times and improving operation efficiency.
2. Continuity of homework: A larger capacity of the medicine box means that it can work continuously for a longer period of time, reducing the number of interruptions caused by medication and thus improving the overall work speed.
3. Time cost: The large capacity of the medicine box allows for the completion of more pesticide applications in the same amount of time, which is particularly important during busy agricultural production seasons.
4. Operational flexibility: For orchards of different sizes and types, suitable capacity medicine boxes can be selected according to actual needs. Small orchards may not require a large medicine box, while large orchards require a large capacity medicine box to reduce the frequency of dosing.
In summary, selecting a suitable capacity medicine box is of great significance for improving pesticide application efficiency, reducing operation time and costs. Users should consider their actual needs and the size of the orchard when choosing to determine the most suitable medicine box capacity.

If you want to get more information about Trailed Spraying Machine, you can contact us at catherine@harvestermachinery.com.
Hot Tags: Trailed Spraying Machine, China, Manufacturers, Suppliers, Factory, Wholesale
